Fire Proof Precast Lightweight Wall Panels For Gypsun Interior Walls , Moisture Resistant

Quick Detail:

Raw materials: MgO,fiber ect.

Size (mm): 2700*600*100

Usages: Interior wall,non-bearing wall

Structure: Hollow core

Density(Kg/m²):42±1.5

Strength(MPa):4.0

Technology:Foaming

Description:

Size(mm):2700*600*100(L*W*T)

Density(Kg/m²):42±1.5

Drying contraction(mm/m):0.25

Softening Cofficient:0.8

Bending Failure Load:2.2

Strength(MPa):3.9

Hanging force(N):＞1000

Moisture(％):7.9

Fire Resistance(h):3

Sound Insulation(dB):41

1. Lightweight: 42kg/m²,low transportion and engineering costs.
2. Strength(4.0MPa): Stable and sturdy

3. Sound& thermal insulation: Easy and comfort would not be disturbed by outside factors.
4. Fire-proof material:over 3 hours, which ensures the security of the whole building. No shape change even in 1100 degree fire.

Applications:

Jumbo lightweight wall panels are widely used as interior walls for commercial and industrial buildings and also are great replacement of blocks.

1) Hotels;

2) Shopping malls;

3) Office buildings;

4) Mansions;

5) High-rise buildings;

6) Residential buildings;

7) Commercial buildings;

8) Houses.

Specification

Competitive Advantage:

Jiangsu Jumbo Buliding material Technologies Co.,Ltd is a professional manufacturer of lightweight wall materials as well as a provider of relevant applications.

We are located in Changzhou City in Jiangsu province. For now we have two production bases,which ensures a capacity of 1.6 million square meters each year.

We have been in this field for over ten years and our experience shows that the importance of installation is the same as the quality itself. So based on the strict quality system, we also train a professional team (more than 100 persons) for installation. We are ready to provide good quality walls and more efficient service!

Jiangsu Jumbo Building Technology Co., Ltd is the biggest manufacture of MgO lightweight partition wall panels in China, with an annual capacity of 3.2 million square meters

The production with our own brand “Jumbo” has passed all tests and inspections of National Quality Supervision and Test Center of Building Materials for Industrial Constructions, National Center for Quality Supervision and Test of Fire Fighting Equipment, ect. Our production has been widely applied in the non-bearing walls of various buildings. We have established stable business relationship with domestic markets ( Hong Kong, Bejing, Shanghai, Jiangsu, Zhejiang and so on) and markets overseas, such as Russia, Papua New Guinea, Angola, etc.

It is well known that science and technology is the primary productive force. So we always focus on new materials and new applications, and we also coordinate with relevant universities and institutes. We believe that the quality is the body, the market is the guide, and research is the spirit. We always value qualified people including engineers, QC, and even workers. Therefore, we are recognized as “Lightweight Partition Wall Expert”.

We have been in this field for over ten years and our experience shows that the importance of installation is the same as the quality itself. So based on the strict quality system, we also train a professional team (more than 100 persons) for installation. We are ready to provide good quality walls and more efficient service!
